| Model | GA3024JMH | GA3524JMH | GA5048JMH | GA5548JMH | |
| Input | Phase | L N PE | |||
| Nominal Voltage | 208/220/230/240VAC | ||||
| Voltage Range | 154-264VAC±3V（Normal Mode) 185-264VAC±3V（UPS Mode） | ||||
| Frequency Range | 50Hz/60Hz(Adaptive) | ||||
| Output | Rated Power | 3000W | 3500W | 5000W | 5500W |
| Output Voltage(AC) | 208/220/230/240VAC±5% | ||||
| Output Frequency | 50/60Hz±0.1% | ||||
| Waveform | Pure sine wave | ||||
| Transfer Time( Optional) | 10ms for computer , 20ms for home appliances | ||||
| Peak power | 6000VA | 7000VA | 10000VA | 11000VA | |
| Overload | "Battery Mode：1min@102%~110% Load 10s@110%~130% Load | ||||
| 3s@130%~150% Load 200ms@>150% Load" | |||||
| Peakefficiency (battery mode) | >94% | >94% | >94% | >94% | |
| Battery | Rated voltage | 24Vdc | 24Vdc | 48Vdc | 48Vdc |
| Constant voltage charging voltage (Optional) | 28.2Vdc | 28.2Vdc | 56.4Vdc | 56.4Vdc | |
| Floating charge voltage (Optional) | 27Vdc | 27Vdc | 54Vdc | 54Vdc | |
| Charger | PV charging method | MPPT | MPPT | MPPT | MPPT |
| PV max input power | 4000W | 4000W | 5500W | 5500W | |
| MPPT tracking range | 120~430Vdc | 120~430Vdc | 120~430Vdc | 120~430Vdc | |
| Max PV input voltage | 500Vdc | 500V | 500Vdc | 500Vdc | |
| Max PV charging current | 60A | 80A | 100A | 100A | |
| Max AC charging current | 60A | 80A | 100A | 100A | |
| Max charging current | 120A | 160A | 100A | 100A | |
| Display | LCD display | Operating mode/load/input/output, etc. | |||
| Communication port | RS232 | 5PIN/Pitcstrong.0mm, baud rate 2400 | |||
| Expansion & configuration port | "2 ×5PIN/Pitcstrong.54mm, lithium battery BMS WIFI card, dry contact card, | communication card, etc." | |||
| Parallel interface | No | Optional | |||
| Environmental parameters | Operating environment temperature | 0~40℃ | |||
| Operating environment humidity | 20%~95%（Non condensing） | ||||
| Storage temperature | -15~60℃ | ||||
| Altitude | "The altitude should not exceed 1000m, derating above 1000m, | ||||
| up to 4000m, refer to IEC62040" | |||||
| noise | ≤ 50db | ||||
| Certifications | EN-IEC 60335-1, EN-IEC 60335-2-29, IEC 62109-1 | ||||
